Pipeline Constant Thermostat
The WZA-CY2 Pipeline Constant Thermostat designed specifically for pipeline temperature control. Its probe is made of copper, contact with the medium, providing precise temperature regulation and suitable for various pipeline systems. It is easy to install and low maintenance costs. It can effectively improve temperature control efficiency and is an ideal choice for industrial and commercial applications.
Model:WZA-CY2
Send Inquiry
Product Description
Pipeline Constant Thermostat Features
WZA-CY WZA-CS WZA-CY WZA-CS Series thermostat of pressure type is applicable for hot water pipeline, boiler, bimetal and
pressure type temperature controllers.
Pipeline Constant Thermostat Technical data
| temperature range: | 0-110°C |
| Probe length: | 8.5cm |
| Probe diameter: | 8mm |
| Rated current: | 220VAC/16A，220VAC/6A |
| Temp Accuracy: | 5%FS |
| Differential stop: | 2-9°C |
| Install thread: | G1/2 |
| Main body temperature tolerance: | 105℃ |
| electric strength: | AC2000V/1min |
| insulation resistance: | ≥100MΩ |
| contact resistance: | ≤50mΩ |
| minimum current: | 200mA |
| Temperature response rate: | ≤1.0℃/min |
| service life: | ≥ 100,000 |
| Test environment temperature: | 23±2℃ |
WZA-CY2 Temperature controller
